Whistle AXR C 10.6 E-MTB Full Carbon - ANTHR / TITAN - eride Size S - WHISTLE New 2026

Component

Frame

Full Carbon frame Toray T700, 29”, Integrated battery, Tapered, Internal routing, Rear travel 160 mm, 12x148 mm E-Thru, UDH hanger

Fork

Fox 38 Float Factory eMTB+, Air, GRIP X, 29", Travel 170 mm, 1.5 Tapered, 15x110 mm

Rear Shock

Fox Float X2 Factory,EVOL, LSR, HSR, 2 Pos-Lever, 230x65

Headset

FSA CRII Dual, 1.5”, Internal routing

Crankset

FSA CK320, 34T MegaTooth

Rear Derailleur

Shimano XT RD-M8250 SGS Di2, 12s

Shifters Levers

Shimano XT SW-M8250 Di2, 12s

Brakes

Shimano XT BR-M8220, Four piston, Rotor CL-800 203 mm / 203 mm

Cassette

Shimano CS-M8200, 12s, 10/51

Pedals

Alu MTB Full +

Wheels

Radiale WX30, Ratchet 36T

Stem

Alu, Barbore 35 mm, Extension S-M frame 35 mm L-XL 50 mm

Handlebar

Alu, 780 mm, Barbore 35 mm, Rise 15 mm

Seatpost

Fox Transfer Factory Kashima, Diameter, 31.6 mm, remote

Saddle

Selle Royal SRX

Tyres

Michelin e-Wild Front&Rear Competition Line, 29"x2.60", Tubeless ready

Weight

22.4kg

Size

40 - 44 - 48

Wheel diameter [inch]

29’’

Gear number

12

Battery

Avinox 800 Wh (Fixed) , weight 3.74 kg ( new 2026)

Charging Time

2.5 hours
